CaLiBO3 R110010

Browse Search Results
<< Previous |  Back to Search Results |  Next >>
Record 639 of 4034


Name: CaLiBO3
RRUFF ID: R110010
Ideal Chemistry: CaLiBO3
Locality: Synthetic
Source: Jin_Xiao Mi [view label]
Owner: RRUFF
Description: Loose aggregate of colorless cubic crystals, mixed with parasibirskite crystals (R110009)
Status: The identification of this mineral has been confirmed by single-crystal X-ray diffraction.
RAMAN SPECTRUM
RRUFF ID:
Sample Description: Unoriented Raman on the primary sample
DOWNLOADS:

  To download sample data,
  please select a specific
  orientation angle.

Direction of polarization of laser relative to fiducial mark:
X Min:    X Max:    X Sort:
BROAD SCAN WITH SPECTRAL ARTIFACTS
RRUFF ID: R110010
Wavelength:
Sample Description: Unoriented Raman on the primary sample
Instrument settings: Thermo Almega XR 532nm @ 100% of 150mW
POWDER DIFFRACTION
RRUFF ID: R110010.9
Sample Description: Single crystal, powder profile is calculated
Cell Refinement Output: a: 6.081(2)Å    b: 6.185(2)Å    c: 13.264(4)Å
alpha: 90°    beta: 90°    gamma: 90°   Volume: 498.8(1)Å3    Crystal System: orthorhombic
DOWNLOADS:

X Min:    X Max:    X Sort:
