Sincosite R141154

Browse Search Results
<< Previous |  Back to Search Results |  Next >>
Record 2 of 3


Name: Sincosite
RRUFF ID: R141154
Ideal Chemistry: Ca(VO)2(PO4)2·4H2O
Locality: South Rasmussen Ridge mine, Caribou County, Idaho, USA
Source: Tom Loomis [view label]
Owner: RRUFF
Description: Both dark brassy green and bright green platy crystals. Crystals twinned by a 2-fold around [1 -1 0].
Status: The identification of this mineral has been confirmed by single-crystal X-ray diffraction.
Mineral Group: [ Sincosite (3) ]
Quick search: [ All Sincosite samples (3) ]
RAMAN SPECTRUM
RRUFF ID:
Sample Description: Unoriented sample
DOWNLOADS:

  To download sample data,
  please select a specific
  orientation angle.
Direction of polarization of laser relative to fiducial mark:
X Min:    X Max:    X Sort:
BROAD SCAN WITH SPECTRAL ARTIFACTS
RRUFF ID: R141154
Wavelength:
Sample Description: Unoriented sample
Instrument settings: Thermo Almega XR 532nm @ 100% of 150mW
DOWNLOADS:

Raman Data (Processed)
RRUFF File
POWDER DIFFRACTION
RRUFF ID: R141154.9
Sample Description: Single crystal, powder profile is calculated
Cell Refinement Output: a: 6.385(1)Å    b: 6.400(1)Å    c: 6.549(1)Å
alpha: 93.62(3)°    beta: 106.43(3)°    gamma: 90.21(3)°   Volume: 256.1(1)Å3    Crystal System: triclinic
DOWNLOADS:
X Min:    X Max:    X Sort:
REFERENCES for Sincosite

American Mineralogist Crystal Structure Database Record: [view record]

Anthony J W, Bideaux R A, Bladh K W, and Nichols M C (1990) Handbook of Mineralogy, Mineral Data Publishing, Tucson Arizona, USA, by permission of the Mineralogical Society of America. [view file]

Schaller W T (1922) Sincosite, a new mineral, Journal of the Washington Academy of Sciences, 12, 195-195   [view file]

Wherry E T (1922) New minerals: new species, American Mineralogist, 7, 162-164   [view file]

Schaller W T (1924) The occurrence and properties of sincosite, a new vanadium mineral from Sincos, Peru, American Journal of Science, 8, 462-480   [view file]

Foshag W F (1925) New mineral names, American Mineralogist, 10, 131-135   [view file]

Zolensky M E (1985) New data on sincosite, American Mineralogist, 70, 409-410   [view file]

Kang H Y, Lee W C, Wang S L (1992) Hydrothermal synthesis and structural characterization of four layered vanadyl(IV) phosphate hydrates A(VO)2(PO4)2·4H2O (A = Co, Ca, Sr, Pb), Inorganic Chemistry, 31, 4743-4748

Franke W A, Luger P, Weber M, Ivanova T I (1997) Low hydrothermal growth of sincosite Ca(VO/PO4)2·4H2O, Zapiski Vserossijskogo Mineralogicheskogo Obshchestva, 126, issue 2 85-86   [view file]
