Glaucophane R050333

Browse Search Results
<< Previous |  Back to Search Results |  Next >>
Record 1 of 3


Name: Glaucophane
RRUFF ID: R050333
Ideal Chemistry:    Na2(Mg3Al2)Si8O22(OH)2
Locality: Cazadero, Sonoma County, California, USA
Source: California Institute of Technology W-204
Owner: RRUFF
Description: Blackish-blue fibrous aggregate
Status: The identification of this mineral has been confirmed by X-ray diffraction and chemical analysis
Mineral Group: [ amphibole (105) ]
Quick search: [ All Glaucophane samples (3) ]
CHEMISTRY
RRUFF ID: R050333.2
Sample Description: Microprobe Fragment
Measured Chemistry:    (Na1.96Ca0.02   0.02)Σ=2(Mg1.89Fe2+1.08Mn0.03)Σ=3(Al1.52Fe3+0.48)Σ=2Si8.00O22(OH)2
RAMAN SPECTRUM
RRUFF ID:
Sample Description: Unoriented sample
DOWNLOADS:

  To download sample data,
  please select a specific
  orientation angle.

Direction of polarization of laser relative to fiducial mark:
X Min:    X Max:    X Sort:
BROAD SCAN WITH SPECTRAL ARTIFACTS
RRUFF ID: R050333
Wavelength:
Sample Description: Unoriented sample
Instrument settings: Thermo Almega XR 532nm @ 100% of 150mW
INFRARED SPECTRUM (Attenuated Total Reflectance)
RRUFF ID: R050333.1
Instrument settings: SensIR Durascope on a Nicolet Magna 860 FTIR
Resolution:
X Min:    X Max:    X Sort:
POWDER DIFFRACTION
RRUFF ID: R050333.1
Sample Description: powder
Cell Refinement Output: a: 9.560(1)Å    b: 17.762(3)Å    c: 5.3045(6)Å
alpha: 90.°    beta: 103.599(7)°    gamma: 90.°   Volume: 875.5(1)Å3    Crystal System: monoclinic
  File Type Information Close
Calculated diffraction file.

  File Type Information Close
Output file from the Bruker D8 Advance instrument. Includes device headers and XY data.

  File Type Information Close
Output file from the Bruker D8 Advance instrument. Includes device headers and XY data.

X Min:    X Max:    X Sort:
REFERENCES for Glaucophane

American Mineralogist Crystal Structure Database Record: [view record]

Anthony J W, Bideaux R A, Bladh K W, and Nichols M C (1990) Handbook of Mineralogy, Mineral Data Publishing, Tucson Arizona, USA, by permission of the Mineralogical Society of America. [view file]

Hausmann J F L (1845) Beiträge zur Oryktographie von Syra, Journal für Praktische Chemie, 1845, 238–241   [view file]

Borg I Y (1967) Optical properties and cell parameters in the glaucophane-riebeckite series, Contributions to Mineralogy and Petrology, 15, 67-92   [view file]

Papike J J, Clark J R, (1968) The crystal structure and cation distribution of glaucophane, American Mineralogist, 53, 1156-1173

Leake B E (1978) Nomenclature of amphiboles, American Mineralogist, 63, 1023-1052   [view file]

Leake B E, Woolley A R, Arps C E S, Birch W D, Gilbert M C, Grice J D, Hawthorne F C, Kato A, Kisch H J, Krivovichev V G, Linthout K, Laird J, Mandarino J A, Maresch W V, Nickel E H, Rock N M S, Schumacher J C, Smith D C, Stephenson N C N, Ungaretti L, Whittaker E J W, Youzhi G (1997) Nomenclature of amphiboles: report of the Subcommittee on Amphiboles of the International Mineralogical Association, Commission on New Minerals and Mineral Names, The Canadian Mineralogist, 35, 219-246   [view file]

Huang E P (2002) Raman spectroscopic study of amphiboles, Doctoral Dissertation, 1, 1-138   [view file]

Leake B E, Woolley A R, Birch W D, Burke E A J, Ferraris G, Grice J D, Hawthorne F C, Kisch H J, Krivovichev V G, Schumacher J C, Stephenson N C N, Whittaker E J W (2003) Nomenclature of amphiboles: additions and revisions to the International Mineralogical Association’s 1997 recommendations, The Canadian Mineralogist, 41, 1355-1362   [view file]

Apopei A I, Buzgar N (2010) The Raman study of amphiboles, Analele Stiintifice Ale Universitatii, Al. I. Cuza Iasi Geologie, 56, 57-83   [view file]

Jenkins D M, Ventura G D, Orberti R, Bozhilov K (2013) Synthesis and characterization of amphiboles along the tremolite-glaucophane join, American Mineralogist, 98, 588-600

Brown J M, Abramson E H (2016) Elasticity of calcium and calcium-sodium amphiboles, Physics of The Earth and Planetary Interiors, 261, 161-171

Thompson E C, Campbell A J, Liu Z (2016) In-situ infrared spectroscopic studies of hydroxyl in amphiboles at high pressure, American Mineralogist, 101, 706-712
